ACM1602K-FLY-YBW Real Image
Same model may have multiple batches, images only for reference.

ACM1602K-FLY-YBW

Part No ACM1602K-FLY-YBW
Manufacturer AZ Displays
Catalog Display Modules - LCD, OLED Character and Numeric
Description 16x2 CHARACTER LCD / Character Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - Yellow/Green 80.00mm x 36.00mm x 13.50mm
Datasheet
ACM1602K-FLY-YBW Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - LCD, OLED Character and Numeric
Mfr AZ Displays
Package Box
Product Status Active
Number of Characters 32
Display Format 16 x 2
Character Format 5 x 8 Dots
Display Type STN - Super-Twisted Nematic
Display Mode Transflective
Character Size 5.23mm H x 3.00mm W
Outline L x W x H 80.00mm x 36.00mm x 13.50mm
Viewing Area 64.50mm L x 16.40mm W
Backlight LED - Yellow/Green
Voltage - Supply 4.8V ~ 5.2V
Dot Size 0.56mm W x 0.61mm H
Controller Type AiP31066LC, ST7066U-0A
Temperature Range - Operating -20°C ~ 70°C
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
HTSUS 8531.20.0020
Win Source Part Number 860805-ACM1602K-FLY-YBW
Ultra Librarian 3D Model Ultra Librarian ACM1602K-FLY-YBW CAD Model

Description

The ACM1602K-FLY-YBW is a 16 x 2 character LCD display from AZ Displays.

  • Display Type: STN (Super-Twisted Nematic)
  • Viewing Area: 64.50mm L x 16.40mm W
  • Character Format: 5 x 8 Dots
  • Character Size: 5.23mm H x 3.00mm W
  • Outline Size: 80.00mm x 36.00mm x 13.50mm
  • Operating Voltage: 4.8V to 5.2V
  • Temperature Range: -20°C to 70°C
  • Backlight: LED (Yellow/Green)
  • Standard Package: 1 pcs
