Same model may have multiple batches, images only for reference.
SRN5020TA-1R2Y Real Image
Same model may have multiple batches, images only for reference.

SRN5020TA-1R2Y

Part No SRN5020TA-1R2Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRN5020TA-1R2Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRN5020TA
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 1.2 µH
Tolerance ±30%
Current Rating (Amps) 3.8 A
Current - Saturation (Isat) 4.8A
Shielding Semi-Shielded
DC Resistance (DCR) 20mOhm
Q @ Freq 15 @ 100kHz
Frequency - Self Resonant 132MHz
Ratings AEC-Q200
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.197" L x 0.197" W (5.00mm x 5.00mm)
Height - Seated (Max) 0.079" (2.00mm)
Base Product Number SRN5020TA
Other Names SRN5020TA-1R2YTR,SRN5020TA-1R2YDKR,SRN5020TA-1R2YCT
Standard Package 2,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274309-SRN5020TA-1R2Y
Ultra Librarian 3D Model Ultra Librarian SRN5020TA-1R2Y CAD Model

Description

The SRN5020TA is a semi-shielded drum core inductor from Bourns Inc.

  • Inductance: 1.2 µH
  • Tolerance: ±30%
  • Core Material: Ferrite
  • Q Value: 15 @ 100kHz
  • DC Resistance: 20mOhm
  • Current Rating: 3.8A
  • Package: Tape and reel
  • AEC-Q200: Rated
  • Frequency Self-Resonant: 132MHz
  • Height: 0.079" (2.00mm)
  • Temperature Range: -55°C to 125°C
