Same model may have multiple batches, images only for reference.
SRP0420-R47K Real Image
Same model may have multiple batches, images only for reference.

SRP0420-R47K

Part No SRP0420-R47K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0420
Package Tape & Reel
Material - Core Metal
Inductance 470 nH
Tolerance ±10%
Current Rating (Amps) 10.5 A
Current - Saturation (Isat) 18A
Shielding Shielded
DC Resistance (DCR) 8.9mOhm Max
Q @ Freq 20 @ 25.2MHz
Frequency - Self Resonant 92MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.173" L x 0.161" W (4.40mm x 4.10mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP0420-R47KDKR,118-SRP0420-R47KCT,118-SRP0420-R47KTR
Standard Package 2,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274211-SRP0420-R47K
Ultra Librarian 3D Model Ultra Librarian SRP0420-R47K CAD Model

Description

The Bourns Inc. SRP0420-R47K is a shielded fixed inductor.

  • Inductance: 470nH
  • Tolerance: ±10%
  • Material: Metal core
  • DC Resistance: 8.9mOhm Max
  • Saturation Current Rating: 18A
  • Current Rating: 10.5A
  • Height: 0.079" (2.00mm)
  • Dimension: 0.173" L x 0.161" W (4.40mm x 4.10mm)
  • Mounting: SMD (SMT)
  • Operating Temperature: -40°C to 125°C
  • Package/Case: Nonstandard
  • Standard Package: 2,500 units
