SRP5020TA-2R2M Real Image
Same model may have multiple batches, images only for reference.

SRP5020TA-2R2M

Part No SRP5020TA-2R2M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP5020TA-2R2M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP5020TA
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Metal
Inductance 2.2 µH
Tolerance ±20%
Current Rating (Amps) 4.2 A
Current - Saturation (Isat) 9A
Shielding Shielded
DC Resistance (DCR) 50mOhm Max
Q @ Freq 16 @ 100kHz
Frequency - Self Resonant 38MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 105°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.224" L x 0.205" W (5.70mm x 5.20mm)
Height - Seated (Max) 0.079" (2.00mm)
Base Product Number SRP5020TA
Other Names SRP5020TA-2R2MTR,SRP5020TA-2R2MCT,SRP5020TA-2R2MDKR
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273887-SRP5020TA-2R2M
Ultra Librarian 3D Model Ultra Librarian SRP5020TA-2R2M CAD Model

Description

The Bourns Inc. SRP5020TA-2R2M is a shielded drum core, wirewound inductor with an inductance of 2.2 µH and a tolerance of ±20%.

  • Material: Metal core
  • Q @ Freq: 16 @ 100kHz
  • DC Resistance (DCR): 50mOhm Max
  • Current Rating: 4.2 A
  • Operating Temperature: -40°C to 105°C
  • Packaging: Tape & reel
  • Package / Case: Nonstandard
  • AEC-Q200: Suitable for applications that require AEC-Q200 ratings
