CDSOD323-T03C Real Image CDSOD323-T03C real image3021
Same model may have multiple batches, images only for reference.
CDSOD323-T03C Real Image CDSOD323-T03C real image3021
CDSOD323-T03C Real Image CDSOD323-T03C real image3021
Same model may have multiple batches, images only for reference.

CDSOD323-T03C

Part No CDSOD323-T03C
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 3.3VWM 19VC SOD323
Datasheet
CDSOD323-T03C Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bourns Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 3.3V
Minimum Breakdown Voltage 4V
Max Clamping Voltage 19V (Typ)
Peak Pulse Current(Ippm) 20A (8/20μs)
Power Dissipation - Pd 350W
Applications General Purpose
Capacitance @ Frequency 3pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOD-323
Win Source Part Number 095020-CDSOD323-T03C
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian CDSOD323-T03C CAD Model

Description

CDSOD323-T03C TVS Diode

The CDSOD323-T03C offers robust protection against voltage transients with its enhanced clamping capability. It is housed in a compact SOD-323 package, making it suitable for a range of compact electronic designs.

Applications

  • Portable devices
  • Smartphones
  • Network peripherals
  • Wearable technology

Features and Benefits

  • Enhanced clamping voltage
  • Compact size for tight designs
  • High reliability and long service life
  • Complies with international safety standards

Engineers will find the CDSOD323-T03C to be a versatile component in safeguarding electronics against transient voltage threats.
