CDSOD323-T12C Real Image CDSOD323-T12C real image3022
Same model may have multiple batches, images only for reference.
CDSOD323-T12C Real Image CDSOD323-T12C real image3022
CDSOD323-T12C Real Image CDSOD323-T12C real image3022
Same model may have multiple batches, images only for reference.

CDSOD323-T12C

Part No CDSOD323-T12C
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 12VWM 28.3VC SOD323
Datasheet
CDSOD323-T12C Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bourns Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 12V
Minimum Breakdown Voltage 13.3V
Max Clamping Voltage 28.3V (Typ)
Peak Pulse Current(Ippm) 11A (8/20μs)
Power Dissipation - Pd 350W
Applications General Purpose
Capacitance @ Frequency 3pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOD-323
Win Source Part Number 095266-CDSOD323-T12C
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Consumer Electronics, Computers & Computer Peripherals, Sensing & Instrumentation, Portable Devices, Imaging, Video & Vision
Ultra Librarian 3D Model Ultra Librarian CDSOD323-T12C CAD Model

Description

CDSOD323-T12C Description

The CDSOD323-T12C offers superior transient voltage suppression, making it ideal for environments prone to electrical surges. Its advanced technology ensures optimal performance and protection.

  • Features and Benefits<ul>
  • Bidirectional protection
  • Fast reaction to voltage spikes
  • Small footprint design
  • Superior thermal conductivity
  • Applications<ul>
  • Data lines protection
  • Communication lines
  • Portable devices
  • Battery-powered equipment

    • Choose the CDSOD323-T12C for a reliable, compact solution that meets your circuit protection needs in various voltage-sensitive applications.
