Same model may have multiple batches, images only for reference.

SRP4020-3R3M

Name: SRP4020-3R3M
Brand: Bourns Inc.
SKU: 960041
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	SRP4020-3R3M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Description	FIXED IND 3.3UH 3.3A 48 MOHM SMD / 3.3 µH Shielded Molded Inductor 3.3 A 48mOhm Max Nonstandard
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP4020
Package	Tape & Reel
Product Status	Obsolete
Type	Molded
Material - Core	Iron
Inductance	3.3 µH
Tolerance	±20%
Current Rating (Amps)	3.3 A
Current - Saturation (Isat)	4.3A
Shielding	Shielded
DC Resistance (DCR)	48mOhm Max
Temperature Range - Operating	-55°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.189" L x 0.157" W (4.80mm x 4.00mm)
Height - Seated (Max)	0.079" (2.00mm)
Base Product Number	SRP4020
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Other Names	SRP40203R3M,SRP4020-3R3MCT,SRP4020-3R3MTR,SRP4020-3R3MDKR,SRP4020-3R3M-ND
Standard Package	2,000
Win Source Part Number	960041-SRP4020-3R3M
Ultra Librarian 3D Model	Ultra Librarian SRP4020-3R3M CAD Model

Alternative Products

Description

Bourns Inc. offers the 960041-SRP4020-3R3M, a molded type shielded fixed inductor.

Series: SRP4020 series
Inductance: 3.3 µH
Tolerance: ±20%
DC Resistance (DCR): 48mOhm Max
Current Rating: 3.3 A
Height-Seated Maximum: 0.079" (2.00mm)
Maximum Operating Temperature: 125 °C
Minimum Operating Temperature: -55 °C
Package/Case: Nonstandard
Dimension: 0.189" L x 0.157" W (4.80mm x 4.00mm)
Status: Obsolete
RoHS: RoHS unaffected
