Same model may have multiple batches, images only for reference.

SRP7030-2R2M

Name: SRP7030-2R2M
Brand: Bourns Inc.
SKU: 518753
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	SRP7030-2R2M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Description	FIXED IND 2.2UH 8A 20 MOHM SMD
Datasheet	SRP7030-2R2M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Inductors, Coils, Chokes
Manufacturer	Bourns Inc.
Packaging	Reel - TR
Status	Active
Type	Wirewound
Material - Core	Iron
Inductance	2.2μH
Tolerance	±20%
Current Rating	8A
Current - Saturation	12A
DC Resistance (DCR)	20 mOhm Max
Temperature Range - Operating	-55°C to 150°C
Frequency - Test	100kHz
Mounting	SMD (SMT)
Height - Seated (Max)	0.126" (3.20mm)
Win Source Part Number	1101955-SRP7030-2R2M
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian SRP7030-2R2M CAD Model

Alternative Products

Description

The Bourns Inc. SRP7030-2R2M is a wirewound inductor.

Current Rating: 8A
Inductance: 2.2μH
Height: 0.126" (3.20mm)
Mounting Type: Surface Mount
Tolerance: ±20%
Core Material: Iron
Supply and Demand Status: Limited
Market Status: Active
Temperature Range: -55°C to 150°C
DC Resistance (DCR): 20 mOhm Max
Suitable for: Various Electronic Applications
