Same model may have multiple batches, images only for reference.

SRP7030-R47M

Name: SRP7030-R47M
Brand: Bourns Inc.
SKU: 676136
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRP7030-R47M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Description	Shielded Power Inductors
Datasheet	SRP7030-R47M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Inductors, Coils, Chokes
Manufacturer	Bourns Inc.
Series	SRP7030
Packaging	Reel - TR
Type	Wirewound
Material - Core	Iron
Inductance	470nH
Tolerance	±20%
Current Rating	17.5A
Current - Saturation	26A
Shielding	Shielded
DC Resistance (DCR)	4.2 mOhm Max
Operating Temperature Range	-55°C ~ 150°C
Test Frequency	100kHz
Mounting	SMD
Package	Nonstandard
Size	0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Maximum)	0.126" (3.20mm)
Win Source Part Number	1258824-SRP7030-R47M
Manufacturer Homepage	www.bourns.com
Family Name	SRP7030
Introduction Date	May 09, 2006
ECCN	EAR99
Country of Origin	Taiwan
Halogen Free	Compliant
Estimated EOL Date	2019
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian SRP7030-R47M CAD Model

Alternative Products

Description

The SRP7030-R47M is a shielded wirewound inductor manufactured by Bourns Inc.

Inductance: 470nH
Current Rating: 17.5A
Tolerance: ±20%
Core Material: Iron
Operating Temperature: -55°C to 150°C
Package: Non-Standard
Packaging: Reel
Height: 0.126"
Supply and Demand Status: Balanced
Popularity: Medium
Compliance: Halogen-Free
