ABA-51563-TR1 Real Image ABA-51563-TR1 real image17061
Same model may have multiple batches, images only for reference.
ABA-51563-TR1 Real Image ABA-51563-TR1 real image17061
ABA-51563-TR1 Real Image ABA-51563-TR1 real image17061
Same model may have multiple batches, images only for reference.

ABA-51563-TR1

Part No ABA-51563-TR1
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description 3.5 GHz Broadband Silicon RFIC Amplifier | IC RF AMP ISM 0HZ-3.5GHZ SOT363
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Tape and Reel
Status Obsolete
Frequency 0Hz ~ 3.5GHz
P1dB 1.8dBm
Gain 21.5dB
Noise Figure 3.7dB ~ 4dB
RF Type ISM
Supply Voltage (V) 4.5V ~ 5.5V
Supply Current 18mA ~ 28mA
Test Frequency 2GHz
Manufacturer Package 6-TSSOP, SC-88, SOT-363
Supplier Device Package SOT-363, SC70
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Win Source Part Number 1135044-ABA-51563-TR1
Manufacturer Homepage www.home.agilent.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian ABA-51563-TR1 CAD Model

Description

The Broadcom Limited ABA-51563-TR1 is an obsolete RF/IF and RFID integrated circuit that operates at a frequency range of 0Hz to 3.5GHz and has a gain of 21.5dB.

  • Frequency Range: 0Hz to 3.5GHz
  • Gain: 21.5dB
  • Supply Current: 18mA to 28mA
  • Noise Figure: 3.7dB to 4dB
  • P1dB: 1.8dBm
  • RF Type: ISM
  • Supplier Device Package: SOT-363, SC70
  • Manufacturer Package: 6-TSSOP, SC-88, SOT-363
  • Supply and Demand Status: Sufficient
  • Manufacturer Pack Quantity: 3,000
  • MSL Level: 1 (Unlimited)
  • Test Frequency: 2GHz
  • Status: Obsolete
