Same model may have multiple batches, images only for reference.

HCPL-061N-500E

Name: HCPL-061N-500E
Brand: Broadcom Limited
SKU: 141828
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL-061N-500E
Manufacturer	Broadcom Limited
Catalog	Optoisolators - Logic Output
Description	OPTOISO 3.75KV OPN COLLECTOR 8SO
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Broadcom Limited
Packaging	Reel - TR
Status	Active
Number of Channels	1
Inputs - Side 1/Side 2	1/0
Isolation Voltage	3750Vrms
Common Mode Transient Immunity (Min)	1kV/μs
Input Type	DC
Output Type	Open Collector, Schottky Clamped
Channel Output Current	50mA
Data Rate	10MBd
Propagation Delay tpLH / tpHL (Max)	100ns, 100ns
Rise and Fall Time	42ns, 12ns
Forward Voltage	1.3V
Continuous forward current- Max	10mA
Supply Voltage - Operating	4.5 V to 5.5 V
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	8-SO
Win Source Part Number	040440-HCPL-061N-500E
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	HCPL-061N
Introduction Date	May 31, 2005
ECCN	EAR99
Country of Origin	Philippines, Singapore
Halogen Free	Compliant
Estimated EOL Date	2024
Quantity per package	1,500
Ultra Librarian 3D Model	Ultra Librarian HCPL-061N-500E CAD Model

Alternative Products

Description

The Broadcom Limited HCPL-061N-500E is an optocoupler with an open collector and Schottky clamped output type.

Data Rate: 10MBd
Forward Voltage: 1.3V
Input Type: DC
Number of Channels: 1
Inputs (Side 1/Side 2): 1/0
Common Mode Transient Immunity (Min): 1kV/μs
Propagation Delay tpLH/tpHL (Max): 100ns
Isolation Voltage: 3750Vrms
Package: 8-SO
Operating Temperature: -40°C to 85°C
Supply Voltage: 4.5V to 5.5V
Rise/Fall Time: 42ns/12ns
Channel Output Current: 50mA
Continuous Forward Current (Max): 10mA
Supply and Demand: Balanced
Pieces per Package: 1,500
