HCPL-2631-000E Real Image HCPL-2631-000E Real Image
Same model may have multiple batches, images only for reference.
HCPL-2631-000E Real Image HCPL-2631-000E Real Image
HCPL-2631-000E Real Image HCPL-2631-000E Real Image
Same model may have multiple batches, images only for reference.

HCPL-2631-000E

Part No HCPL-2631-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description Optocoupler Logic-Out Open Collector DC-IN 2-CH 8-Pin PDIP Tube / OPTOISO 3.75KV 2CH OPEN COL 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 10kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Rise and Fall Time 24ns, 10ns
Forward Voltage 1.5V
Continuous forward current- Max 15mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 090894-HCPL-2631-000E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Motor Drive & Control, Industrial, Computers & Computer Peripherals
Quantity per package 50
Family Name HCPL-2631
Introduction Date November 25, 1996
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HCPL-2631-000E CAD Model

Description

The Broadcom Limited 090894-HCPL-2631-000E is an active electronic component.

  • Data Rate: 10MBd
  • Channels: 2
  • Output Type: Open Collector, Schottky Clamped
  • Input Type: DC
  • Inputs on Side 1: 2
  • Inputs on Side 2: 0
  • Common Mode Transient Immunity (Min): 10kV/μs
  • Propagation Delay tpLH / tpHL (Max): 100ns, 100ns
  • Isolation Voltage: 3750Vrms
  • Family Name: HCPL-2631
  • Operating Temperature: -40°C to 85°C
  • Operating Supply Voltage: 4.5V to 5.5V
  • Rise Time: 24ns
  • Fall Time: 10ns
  • Channel Output Current: 50mA
  • Continuous Forward Current (Max): 15mA
  • Alternative Parts: TLP2631-L1, TLP2631, TLP2631F, TLP2631(TP1)
  • Applications: Power management, motor drive & control, industrial, computers & computer peripherals
  • Supply and Demand Status: Balanced
  • Package: 50
