MGA-634P8-TR1G Real Image MGA-634P8-TR1G Real Image1 MGA-634P8-TR1G Real Image2 MGA-634P8-TR1G Real Image3
Same model may have multiple batches, images only for reference.
MGA-634P8-TR1G Real Image MGA-634P8-TR1G Real Image1 MGA-634P8-TR1G Real Image2 MGA-634P8-TR1G Real Image3
MGA-634P8-TR1G Real Image MGA-634P8-TR1G Real Image1 MGA-634P8-TR1G Real Image2 MGA-634P8-TR1G Real Image3
Same model may have multiple batches, images only for reference.

MGA-634P8-TR1G

Part No MGA-634P8-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description IC LNA ULTRA LOW NOISE ACT BIAS / RF Amp Single LNA 1.9GHz 5.5V 8-Pin QFN EP T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Frequency 1.5GHz to 2.3GHz
P1dB 21dBm (125.9mW)
Gain 17.4dB
Noise Figure 0.44dB
RF Type CDMA, GSM
Supply Voltage - Operating 5V
Operating Supply Current 48mA
Test Frequency 1.9GHz
Case / Package 8-QFN (2x2)
Win Source Part Number 023211-MGA-634P8-TR1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 3k pcs
Family Name MGA-634P8
Introduction Date April 01, 2004
ECCN 5A991.g
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian MGA-634P8-TR1G CAD Model

Description

The Broadcom Limited MGA-634P8-TR1G is a CDMA, GSM RF type with a gain of 17.4dB and a noise figure of 0.44dB.

  • Gain: 17.4dB
  • Noise Figure: 0.44dB
  • Test Frequency: 1.9GHz
  • Frequency Range: 1.5GHz to 2.3GHz
  • P1dB: 21dBm (125.9mW)
  • Supply Voltage: 5V
  • Current: 48mA
  • Package: 8-QFN (2x2)
  • Compliance: Halogen-free compliant
  • Supply and Demand Status: Limited
  • Package Contains: 3,000 pieces
