PS2502-4 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Isolators - Optoisolators - Transistor, Photovoltaic Output Optoisolators
Mfr CEL
Series NEPOC
Package Tube
Product Status Obsolete
Number of Channels 4
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Min) 200% @ 1mA
Rise / Fall Time (Typ) 100µs, 100µs
Input Type DC
Output Type Darlington
Voltage - Output (Max) 40V
Current - Output / Channel 160mA
Voltage - Forward (Vf) (Typ) 1.17V
Current - DC Forward (If) (Max) 80 mA
Vce Saturation (Max) 1V
Temperature Range - Operating -55°C ~ 100°C
Mounting Type Through Hole
Package / Case 16-DIP (0.300", 7.62mm)
Supplier Device Package 16-DIP
Standard Package 20 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 656779-PS2502-4
Ultra Librarian 3D Model Ultra Librarian PS2502-4 CAD Model

Description

The 656779-PS2502-4 is a photovoltaic output optoisolator designed for isolation applications. It is part of the NEPOC series and features four channels.

  • Series: NEPOC
  • Channels: four
  • Output Type: Darlington
  • Input Type: DC
  • Maximum Forward Current: 80mA
  • Forward Voltage: 1.17V
  • Rise/Fall Time: 100μs
  • Output Current per Channel: 160mA
  • Voltage Isolation: 5000Vrms
  • Mounting: through-hole
  • Package: 16-DIP
  • Operating Temperature Range: -55°C to 100°C
  • Product Status: obsolete
  • Supplier: CEL
