2N7002 TR Real Image 2N7002 TR Real Image
Same model may have multiple batches, images only for reference.
2N7002 TR Real Image 2N7002 TR Real Image
2N7002 TR Real Image 2N7002 TR Real Image
Same model may have multiple batches, images only for reference.

2N7002 TR

Part No 2N7002 TR
Manufacturer Central Semiconductor Corp
Catalog FETs - Single
Description Trans MOSFET N-CH Si 60V 0.115A 3-Pin SOT-23 T/R / MOSFET N-CH 60V 0.115A SOT-23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Central Semiconductor Corp
Standard Package 1
Category Discrete Semiconductor Products
Family FETs - Single
Packaging Reel
FET Type MOSFET N-Channel Metal Oxide
FET Feature Standard
Drain to Source Voltage (Vdss) 60V
Current - Continuous Drain (Id) @ 25°C 115mA (Tc)
Rds On (Max) @ Id Vgs 7.5 Ohm @ 500mA 10V
Vgs(th) (Max) @ Id 2.5V @ 250µA
Input Capacitance (Ciss) @ Vds 50pF @ 25V
Power - Max 350mW
Operating Temperature Range -65°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package TO-236-3 SC-59 SOT-23-3
Manufacturer Device Package SOT-23
Catalog N-Channel Standard FETs
Win Source Part Number 038882-2N7002 TR
Popularity Medium
Supply and Demand Status Balance
Family Name 2N7002
Introduction Date August 14, 1997
ECCN EAR99
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian 2N7002 TR CAD Model

Description

Overview

The 2N7002 TR is an N-channel MOSFET developed for a wide range of power supply applications. It comes in a convenient SOT-23 package for surface-mounted devices.

Applications

  • Low-voltage circuits
  • Switching applications
  • Load switching in portable devices

Features and Benefits

  • Low gate charge for efficient switching
  • Improved thermal conductivity
  • Compact SOT-23 package
  • Effective for DC-DC converter designs

Perfect for engineers seeking to optimize space and performance in compact electronic designs.
