The 2N7002DSPT is a small signal MOSFET transistor manufactured by Chenmko. This device is commonly used for low-power switching and amplification applications. It's a N-Channel enhancement mode transistor housed in a small SOT-363 (SC-88) package, making it suitable for high-density circuit designs.

Applications

• Low-side switching
• Level shifting
• Portable equipment
• DC-DC converters
• Analog switches

Features

• N-Channel enhancement mode
• Low threshold voltage
• Fast switching speed
• Small SOT-363 (SC-88) package
• RoHS compliant

Benefits

• Reduces board space due to its small size
• Enables efficient switching at low voltage levels
• Improves system performance with fast switching speeds
• Simplified gate drive requirements
• Environmentally friendly due to RoHS compliance

Additional Details

The 2N7002DSPT operates with a gate-source voltage (Vgs) typically between 1.0V and 3.0V. The drain-source voltage (Vds) rating and continuous drain current (Id) ratings should be consulted in the datasheet for proper application. The low on-resistance (Rds(on)) minimizes power dissipation during switching. The SOT-363 package allows for efficient heat dissipation. The device is suitable for battery-powered applications due to its low power consumption. The device is constructed using high-quality materials to ensure long-term reliability. It's often used in circuits where space is a premium and efficient switching is required. It is designed to be compatible with standard pick-and-place assembly equipment. Proper handling precautions should be observed to prevent electrostatic discharge (ESD) damage. This MOSFET is a cost-effective solution for various low-power switching and amplification needs. It is commonly found in consumer electronics, industrial controls, and communication equipment.
