Same model may have multiple batches, images only for reference.

S-1031A

Name: S-1031A
Brand: Copal Electronics Inc.
SKU: 509901
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	S-1031A
Manufacturer	Copal Electronics Inc.
Catalog	DIP Switches
Description	Switch DIP N.O./N.C. SP16T 16 Flush Screwdriver 0.1A 5VDC PC Pins Thru-Hole Bulk / SW ROTARY DIP HEX COMP 100MA 5V
Datasheet	S-1031A Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Switches
Manufacturer	Copal Electronics Inc.
Packaging	Bulk
Status	Active
Circuit	Hexadecimal Complement
Number of Positions	16
Current Rating	100mA
Voltage Rating	5VDC
Actuator Type	Rotary for Tool
Actuator Level	Flush, Recessed
Contact Finish	Gold
Height Above Board	0.394" (10.00mm)
Mounting	Through Hole, Right Angle
Termination Style	PC Pin
Pitch	0.100" (2.54mm), Full
Washable	Yes
Body Material	Polybutylene Terephthalate (PBT)
Length	0.393" (10.00mm)
Temperature Range - Operating	-40°C to 85°C
Electrical Life	10,000 Steps
Win Source Part Number	1093206-S-1031A
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	S-1000A
Introduction Date	November 07, 2004
ECCN	EAR99
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian S-1031A CAD Model

Alternative Products

Description

The Copal Electronics Inc. S-1000A series rotary switch is a high-quality electronic component designed for use in a wide range of applications.

Manufacturer: Copal Electronics Inc.
Positions: 16
Pitch: 0.100" (2.54mm)
Termination Style: PC Pin
Contact Finish: Gold
Voltage Rating: 5VDC
Current Rating: 100mA
Washable: Yes
Mechanical Life: 10,000 steps
Temperature Range: -40°C to 85°C
