Same model may have multiple batches, images only for reference.
SLPX561M220A7P3 Real Image
Same model may have multiple batches, images only for reference.

SLPX561M220A7P3

Part No SLPX561M220A7P3
Manufacturer Cornell Dubilier Electronics (CDE)
Catalog Aluminum Capacitors
Datasheet
SLPX561M220A7P3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Aluminum Electrolytic Capacitors
Mfr Cornell Dubilier Electronics (CDE)
Series SLPX
Package Bulk
Capacitance 560 µF
Tolerance ±20%
Voltage - Rated 220 V
ESR (Equivalent Series Resistance) 355mOhm @ 120Hz
Lifetime @ Temp. 3000 Hrs @ 85°C
Temperature Range - Operating -40°C ~ 85°C
Polarization Polar
Applications General Purpose
Ripple Current @ Low Frequency 2.22 A @ 120 Hz
Ripple Current @ High Frequency 3.26 A @ 20 kHz
Lead Spacing 0.394" (10.00mm)
Dimension 0.866" Dia (22.00mm)
Height - Seated (Max) 1.575" (40.00mm)
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Standard Package 100
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0040
Win Source Part Number 1307564-SLPX561M220A7P3
Ultra Librarian 3D Model Ultra Librarian SLPX561M220A7P3 CAD Model

Description

The Cornell Dubilier Electronics (CDE) SLPX series aluminum electrolytic capacitor with Win Source Part Number 1307564-SLPX561M220A7P3 has a capacitance of 560 µF with a voltage rating of 220V.

  • Capacitance: 560 µF
  • Voltage Rating: 220V
  • Application: General-purpose
  • Mounting Type: Through-hole
  • Package: Radial, can-snap-in
  • Tolerance: ±20%
  • ESR (Equivalent Series Resistance): 355mOhm @ 120Hz
  • Lifetime: 3000 Hrs @ 85°C
  • Polarized: Yes
  • Dimensions: 0.866" Dia (22.00mm)
  • Operating Temperature: -40°C to 85°C
