MGS1R5243R3 Real Image
Same model may have multiple batches, images only for reference.

MGS1R5243R3

Part No MGS1R5243R3
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 3.3V / Isolated Module DC DC Converter 1 Output 3.3V 400mA 18V - 36V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Cosel USA, Inc.
Series MGS (1.5W)
Package Box
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 18V
Voltage - Input (Max) 36V
Voltage - Output 1 3.3V
Current - Output (Max) 400mA
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features OCP
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 78%
Mounting Type Through Hole
Package / Case 4-SIP Module
Size / Dimension 0.67" L x 0.33" W x 0.47" H (17.0mm x 8.5mm x 12.0mm)
Base Product Number MGS1R5243
Standard Package 1
MSL Level Not Applicable
ECCN EAR99
HTSUS 8504.40.9580
California Prop 65 Warning Information
Win Source Part Number 1337500-MGS1R5243R3
Ultra Librarian 3D Model Ultra Librarian MGS1R5243R3 CAD Model

Description

The Cosel USA MGS1R5243R3 is a 1.5W isolated module DC-DC converter that is designed for ITE (Commercial) applications.

  • Manufacturer: Cosel USA
  • Power Rating: 1.5W
  • Isolation: Isolated Module
  • Application: ITE (Commercial)
  • Overcurrent Protection: Yes
  • Package: Box
  • Dimensions: 0.67" L x 0.33" W x 0.47" H (17.0mm x 8.5mm x 12.0mm)
  • Output Count: Single
  • Maximum Output Current: 400mA
  • Output Voltage: 3.3V
  • Input Voltage Range: 18V to 36V
  • Efficiency: 78%
  • Temperature Range: -40°C ~ 85°C
  • Series: MGS
