XTEHVW-Q0-0000-00000LBF8 Cree Inc.
Same model may have multiple batches, images only for reference.

XTEHVW-Q0-0000-00000LBF8

Part No XTEHVW-Q0-0000-00000LBF8
Manufacturer Cree Inc.
Catalog LED Lighting - White
Description XLamp XT-E High-Voltage White LEDs | LED XLAMP WARM WHITE 2850K 2SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Optoelectronics
Manufacturer Cree Inc.
Packaging Tape and Reel
Status Obsolete
Color White, Warm
CCT (K) 2850K
Flux at 85°C, Current - Test 97lm (94lm ~ 100lm)
Current - Test 22mA
Voltage - Forward (Vf) 48V
Lumens/Watt at Current - Test 92 lm/W
CRI (Color Rendering Index) 82
Current - Max 66mA
Viewing Angle 115°
Mounting Style SMD
Manufacturer Package 1414 (3535 Metric)
Parts Dimension 0.136" L x 0.136" W (3.45mm x 3.45mm)
Height - Seated (Maximum) 0.098" (2.49mm)
Thermal Resistance of Package 6.5°C/W
Family Part Number XTEHVW
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Win Source Part Number 1282412-XTEHVW-Q0-0000-00000LBF8
Manufacturer Homepage www.cree.com/
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian XTEHVW-Q0-0000-00000LBF8 CAD Model

Description

The Cree Inc. XTEHVW-Q0-0000-00000LBF8 is a white, warm SMD LED component with a maximum current of 66mA and a test current of 22mA.

  • Current (Max): 66mA
  • Current (Test): 22mA
  • Viewing Angle: 115 degrees
  • CCT: 2850K
  • CRI: 82
  • Thermal Resistance: 6.5 degrees Celsius per watt
  • Category: Optoelectronics
  • Product Status: Obsolete
  • Manufacturer Package: 1414 (3535 Metric)
  • Height: 0.098 inches (2.49mm)
  • Supply and Demand Status: Sufficient
  • Manufacturer Homepage: www.cree.com/
  • Parts Dimension: 0.136 inches L x 0.136 inches W (3.45mm x 3.45mm)
  • Voltage-Forward (Vf): 48V
  • Flux @ 85 degrees Celsius, Current-Test: 97lm (94lm ~ 100lm)
  • Lumens/Watt @ Current-Test: 92 lm/W
