ATS036SM CTS Corporation
Same model may have multiple batches, images only for reference.

ATS036SM

Part No ATS036SM
Manufacturer CTS-Frequency Controls
Catalog Oscillators
Description 0003.579545 MHZ Crystal
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators - Crystals
Mfr CTS-Frequency Controls
Series ATS-SM
Package Bulk
Product Status Active
Type MHz Crystal
Frequency 3.579545 MHz
Frequency Stability ±50ppm
Frequency Tolerance ±30ppm
Load Capacitance 18pF
ESR (Equivalent Series Resistance) 150 Ohms
Operating Mode Fundamental
Temperature Range - Operating -20°C ~ 70°C
Mounting Type Surface Mount
Package / Case HC-49/US
Size / Dimension 0.437" L x 0.190" W (11.10mm x 4.83mm)
Height - Seated (Max) 0.437" L x 0.190" W (11.10mm x 4.83mm)
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.60.0030
Win Source Part Number 566831-ATS036SM
Ultra Librarian 3D Model Ultra Librarian ATS036SM CAD Model

Description

The 566831-ATS036SM is a 3.579545 MHz crystal from CTS-Frequency Controls. Bold the product name (e.g., BAV99S,135 → 566831-ATS036SM) and manufacturer (e.g., Nexperia USA Inc. → CTS-Frequency Controls).

  • Series: ATS-SM
  • Frequency: 3.579545 MHz
  • Type: Crystal
  • Mounting Type: Surface Mount
  • Package Size: 0.437" L x 0.190" W (11.10mm x 4.83mm)
  • Height: 0.437" L x 0.190" W (11.10mm x 4.83mm)
  • Load Capacitance: 18pF
  • Mode: Fundamental
  • Frequency Stability: ±50ppm
  • Frequency Tolerance: ±30ppm
  • Operating Temperature: -20°C to 70°C
  • Applications: Communication systems, digital devices, and consumer electronics
  • Features: Accurate and stable frequency output
