The AP7346D-1815FS6-7 is a low dropout (LDO) regulator designed and manufactured by Diodes Incorporated, a leading global manufacturer and supplier of high-quality application-specific standard products within the broad discrete and semiconductor markets. This LDO regulator is specifically engineered to deliver a stable and reliable power supply in various electronic applications.

Key Features

• Output Voltage: This component offers a fixed output voltage of 1.815V, which is ideal for powering sensitive electronics that require a precise voltage level.
• High Accuracy: The output voltage accuracy is maintained within ±1%, ensuring a stable and consistent power supply for critical applications.
• Low Dropout Voltage: The AP7346D-1815FS6-7 boasts a low dropout voltage, which enhances its efficiency and allows it to operate effectively even when the input voltage is very close to the output voltage.
• Current Capacity: It can deliver up to 150mA of continuous output current, catering to a wide range of power requirements.
• Package: Housed in a small SOT-563 package, the device occupies minimal space on a circuit board, making it suitable for compact electronic designs.
• Power Saving: With a quiescent current as low as 25µA, it contributes to the energy efficiency of the overall system by reducing standby power consumption.
• Protection Features: It includes over-current protection and thermal shutdown features to safeguard the device and the system it powers from potential damage due to abnormal operating conditions.

Applications

The AP7346D-1815FS6-7 LDO regulator is versatile and can be used in a variety of applications, including but not limited to:

• Battery-powered devices
• Portable and handheld equipment
• Microprocessor/microcontroller power supply
• Wireless communication devices
• Power management for IoT devices

With its compact footprint, high accuracy, and energy-saving features, the AP7346D-1815FS6-7 from Diodes Incorporated is an excellent choice for designers looking for a reliable LDO regulator for their next project.
