The B280-13-F is a robust rectifier diode designed and manufactured by Diodes Incorporated, a leading global provider of high-quality semiconductor products. This surface-mount Schottky barrier rectifier is engineered to offer efficient and reliable performance for a wide range of applications, including power management, conversion, and protection circuits.

Key Features

• High Current Capability: With a forward continuous current of 2.0A, the B280-13-F can handle significant current loads, making it suitable for high-power applications.
• Low Forward Voltage Drop: The device exhibits a low forward voltage drop, which enhances system efficiency by minimizing power loss during operation.
• High Surge Capability: The rectifier is capable of withstanding high surge currents, providing robust protection against transient voltage spikes.
• Power Dissipation: It has a power dissipation of 1.25W, which ensures that the device can manage the heat generated during high-power operations.

Electrical Characteristics

• Maximum Repetitive Reverse Voltage: 80V
• Maximum RMS Voltage: 56V
• Forward Continuous Current: 2.0A
• Maximum Forward Voltage Drop at 2.0A: 0.85V
• Maximum Reverse Current at Rated DC Blocking Voltage: 500μA

Applications

Thanks to its high efficiency and reliability, the B280-13-F is ideal for use in a variety of electronic circuits, including:

• Switching power supplies
• Power converters
• Free-wheeling diodes
• Polarity protection devices
• DC-DC converters

Package and Quality

The B280-13-F comes in an SMB package, which is not only compact but also offers excellent thermal performance. Diodes Incorporated is committed to high standards of quality, and this product is no exception. It is RoHS compliant and meets the requirements for lead-free construction, ensuring that it is suitable for use in environmentally sensitive applications.

With its combination of high current capability, low power loss, and robust surge protection, the B280-13-F from Diodes Incorporated stands out as a high-performance solution for your rectification needs.
