Product Overview: BAT54LP-7B

The BAT54LP-7B from Diodes Incorporated is a high-performance Schottky barrier diode designed for voltage clamping applications, efficient rectification, and switching with fast switching speeds. This diode is housed in a leadless DFN1006-2 package, which offers a compact footprint for space-constrained applications while providing excellent thermal performance.

Key Features

• Low Forward Voltage Drop: The BAT54LP-7B boasts a low forward voltage drop, which enhances its efficiency in applications that require high-frequency rectification.
• Surface Mount Package: Its DFN1006-2 (SOD882) package is ideal for automatic pick-and-place assembly processes, ensuring a streamlined manufacturing workflow.
• High Switching Speed: With its Schottky barrier design, this diode provides ultra-fast switching, making it suitable for high-speed circuitry and frequency applications.
• Low Capacitance: The device features low diode capacitance, which is beneficial for high-frequency and RF applications where capacitance can impact signal integrity.
• Lead-Free and RoHS Compliant: The BAT54LP-7B is environmentally friendly, complying with current RoHS standards, which restrict the use of certain hazardous substances in electronic equipment.

Applications

The design and electrical characteristics of the BAT54LP-7B make it a versatile component suitable for a wide range of applications, including:

• Power management systems
• DC-DC converters
• Charge and discharge circuits for battery protection
• Voltage clamping applications
• Reverse polarity protection circuits
• Logic level shifting circuits

Product Specifications

The BAT54LP-7B operates with a repetitive peak reverse voltage of 30V and a continuous forward current of 200mA. Its low forward voltage drop and high surge current capability make it a reliable choice for high-efficiency designs.

Engineers and designers looking for a compact, high-efficiency Schottky diode will find the BAT54LP-7B from Diodes Incorporated to be an ideal choice for their circuit designs. Its robust performance and small form factor make it a go-to component for modern electronic applications.
