The DDZ9689S-7 is a high-quality Zener diode from Diodes Incorporated, designed to provide precision voltage regulation in a wide array of electronic applications. This surface-mount device is housed in a compact SOD-323 package, making it suitable for high-density circuit boards where space is at a premium.

Key Features

• Nominal Zener Voltage: The DDZ9689S-7 has a Zener voltage of 3.6V, which is ideal for providing a stabilized voltage reference in various circuits.
• Power Dissipation: With a power dissipation of 500mW, this diode can handle significant power levels, making it suitable for a wide range of applications.
• Tolerance: It offers a ±3% tolerance, ensuring precise voltage regulation for sensitive electronic components.
• Operating Temperature: This Zener diode operates within a temperature range of -55°C to +150°C, providing reliable performance under extreme conditions.
• Package: The SOD-323 package is not only compact but also offers excellent thermal performance for its size.

Applications

The DDZ9689S-7 is versatile and can be used in various applications, including:

• Voltage regulation modules
• Over-voltage protection circuits
• Switching power supplies
• Consumer electronics
• Computers and computer peripherals

Quality and Reliability

Diodes Incorporated is known for its commitment to quality, and the DDZ9689S-7 is no exception. It is manufactured to meet strict industry standards, ensuring high reliability and performance in your electronic projects. Whether for commercial, industrial, or personal use, this Zener diode stands out for its precision voltage control and robust design.

Ordering Information

The product is available in tape and reel packaging, facilitating easy integration into automated assembly processes. For detailed ordering and shipping information, please refer to the Diodes Incorporated website or contact authorized distributors.
