DMP2165UW-7

Part No DMP2165UW-7
Manufacturer Diodes Incorporated
Catalog FETs - Single
Description MOSFET BVDSS: 8V-24V SOT323 T&R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Diodes Incorporated
Packaging Reel
FET Type P-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 20V
Current - Continuous Drain (Id) at 25°C 2.5A
Drive Voltage (Max Rds On, Min Rds On) 1.8V, 4.5V
Rds On (Maximum) at Id, Vgs 90mOhm at 1.5A, 4.5V
Vgs(th) (Maximum) at Id 1V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 3.5nC at 4.5V
Maximum Vgs ±12V
Input Capacitance (Ciss) (Maximum) at Vds 335pF at 15V
Power Dissipation (Maximum) 500mW
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Supplier Device Package SOT-323
Manufacturer Package SC-70, SOT-323
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Balance
Win Source Part Number 802162-DMP2165UW-7
Ultra Librarian 3D Model Ultra Librarian DMP2165UW-7 CAD Model

Description

Overview of DMP2165UW-7 P-Channel MOSFET

The DMP2165UW-7 is a high-performance P-Channel enhancement mode Field-Effect Transistor (MOSFET) designed and manufactured by Diodes Incorporated. This semiconductor device is well-suited for power management applications due to its low on-resistance and high switching speed.

Key Features

  • Device Type: P-Channel MOSFET
  • Configuration: Single
  • Drain-Source Breakdown Voltage: -20 V
  • Continuous Drain Current: -3.7 A
  • RDS(on): 65 mΩ at VGS = -4.5 V
  • Power Dissipation: 1.4 W
  • Operating Temperature Range: -55°C to +150°C
  • Mounting Type: Surface Mount
  • Package / Case: SOT-323-3

Applications

The DMP2165UW-7 is particularly useful in a variety of applications that require efficient power management. Some of these applications include:

  • Load Switch
  • Battery Management
  • Power Supply Conversion
  • DC-DC Converters
  • Portable Devices

Benefits

Engineers and designers may opt for the DMP2165UW-7 due to its numerous advantages:

  • The low threshold voltage allows for operation at lower gate voltages, making it suitable for low voltage applications.
  • High efficiency is achieved through reduced conduction losses, thanks to its low on-resistance.
  • The small SOT-323 package is ideal for space-constrained applications, enabling compact circuit design.
  • It offers robust thermal performance, ensuring reliability over a wide range of operating conditions.

Quality and Reliability

Diodes Incorporated is known for their commitment to quality, and the DMP2165UW-7 is no exception. It is RoHS compliant and adheres to the highest industry standards for reliability and environmental safety, making it a preferred choice for both commercial and industrial applications.

For detailed specifications, application notes, and additional resources, interested parties are encouraged to visit the official Diodes Incorporated website or contact their local sales representative.
