Product Overview: MMBT3904LP-7

Manufacturer: Diodes Incorporated

The MMBT3904LP-7 is a high-performance NPN bipolar junction transistor (BJT) designed for versatile applications in today's electronic circuits. This compact surface-mount transistor is part of Diodes Incorporated's broad range of discrete semiconductor products, known for their reliability and efficiency.

Key Features

• Low Power Consumption: The MMBT3904LP-7 is designed for low power applications, making it ideal for portable and battery-powered devices.
• High Current Gain Bandwidth Product: With an excellent gain bandwidth product, this transistor is suitable for amplification and switching applications that require high frequency performance.
• Surface-Mount Package: The SOT-523 package allows for a compact footprint on printed circuit boards (PCBs), optimizing space without compromising performance.
• Lead-Free and RoHS Compliant: This product meets environmental standards, ensuring compatibility with green manufacturing processes.

Applications

The MMBT3904LP-7 is widely used in a variety of applications, including:

• Signal amplification in audio and video equipment
• Driver stages in amplifiers and switches
• Low-power consumption applications
• Portable and wearable technology
• General-purpose switching and amplification

Electrical Characteristics

With a collector-emitter voltage (Vce) of 40V and a collector current (Ic) of 200mA, the MMBT3904LP-7 is capable of handling moderate power levels. It also features a collector-base voltage (Vcb) of 60V and an emitter-base voltage (Veb) of 6V, providing a good range of operation for various circuit designs.

The MMBT3904LP-7 is a testament to Diodes Incorporated's commitment to providing high-quality, versatile components for the electronics industry. Whether for commercial, industrial, or consumer applications, this transistor offers a balance of performance and compact packaging that can meet the demands of modern electronic designs.
