Diodes Incorporated PI7C1401AZFEX Overview

The PI7C1401AZFEX is a high-performance, four-port PCI Express packet switch designed by Diodes Incorporated, offering an efficient solution for expanding PCI Express connectivity in various computing and embedded systems. It is part of the PI7C1401 series known for its reliability and versatility in handling PCIe signals.

Key Features

• PCI Express Base Specification Compliance: The product is compliant with PCI Express Base Specification Revision 2.1, ensuring compatibility with a wide range of PCIe devices and systems.
• Port Configuration: It features four downstream ports that enable the connection of multiple devices, maximizing the usage of a single PCIe slot on the motherboard.
• High Performance: With support for high-speed data transfer rates, this switch can handle the rigorous demands of modern applications, including data centers, servers, and high-end computing tasks.
• Low Power Consumption: Designed with power efficiency in mind, the PI7C1401AZFEX helps to reduce overall system power usage, which is crucial for energy-sensitive environments.
• Advanced Error Reporting: The switch includes advanced error reporting capabilities to detect and report data transmission errors, ensuring data integrity and reliability.

Applications

The PI7C1401AZFEX is suitable for a variety of applications where expanding PCIe connectivity is necessary. It is commonly used in:

• Servers and Workstations
• Embedded Systems
• Network and Communication Devices
• Storage Systems
• Industrial Computers

Product Specifications

The switch is packaged in a 15x15 mm² 144-pin TQFP (Thin Quad Flat Pack), making it suitable for compact systems without sacrificing performance. Its operating temperature range is from 0°C to 70°C, which allows for its use in standard commercial environments. The PI7C1401AZFEX also supports hot-plug operations, making it easy to add or remove devices without needing to power down the system.

Overall, the PI7C1401AZFEX from Diodes Incorporated is a robust and efficient solution for system designers looking to enhance PCIe connectivity while maintaining high performance and reliability.
