Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr DIOTEC Electronics Corporation
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 1 V @ 2 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 50 ns
Current - Reverse Leakage @ Vr 5 µA @ 100 V
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Supplier Device Package DO-214AA (SMB)
Operating Temperature - Junction -50°C ~ 150°C
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
HTSUS 8541.10.0000
Win Source Part Number 695521-US2B
Ultra Librarian 3D Model Ultra Librarian US2B CAD Model

Description

The 695521-US2B is a fast recovery diode rectifier designed for applications requiring a voltage rating of up to 100V and an average rectified current of 2A.

  • Voltage Rating: Up to 100V
  • Average Rectified Current: 2A
  • Forward Voltage: 1V @ 2A
  • Reverse Recovery Time: 50ns
  • Current Leakage @ Maximum Reverse Voltage: 5μA
  • Package: Surface Mount DO-214AA (SMB)
  • Standard Package: 3,000 pieces
  • Manufacturer: DIOTEC Electronics Corporation
  • Product Status: Active
