Same model may have multiple batches, images only for reference.

B82432C1182K000

Name: B82432C1182K000
Brand: EPCOS (TDK)
SKU: 1348537
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	B82432C1182K000
Manufacturer	EPCOS (TDK)
Catalog	Fixed Inductors
Description	FIXED IND 1.8UH 490MA 410MOHM SM / 1.8 µH Unshielded Drum Core, Wirewound Inductor 490 mA 410mOhm Max 2-SMD, J-Lead
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	EPCOS - TDK Electronics
Series	SIMID
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	1.8 µH
Tolerance	±10%
Current Rating (Amps)	490 mA
Shielding	Unshielded
DC Resistance (DCR)	410mOhm Max
Q @ Freq	40 @ 7.96MHz
Frequency - Self Resonant	100MHz
Ratings	AEC-Q200
Temperature Range - Operating	-55°C ~ 125°C
Inductance Frequency - Test	1 MHz
Mounting Type	Surface Mount
Package / Case	2-SMD, J-Lead
Supplier Device Package	1812 (4532 Metric)
Size / Dimension	0.177" L x 0.126" W (4.50mm x 3.20mm)
Height - Seated (Max)	0.134" (3.40mm)
Standard Package	5,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	1348537-B82432C1182K000
Ultra Librarian 3D Model	Ultra Librarian B82432C1182K000 CAD Model

Alternative Products

Description

The SIMID series of fixed inductors from EPCOS (TDK Electronics) is a high-quality and reliable solution for surface mount applications.

Inductance: 1.8 µH
Current Rating: 490 mA
Tolerance: ±10%
Q: 40 @ 7.96MHz
Frequency Self-Resonant: 100MHz
DC Resistance: 410mOhm max
Mounting Type: Surface Mount
Package: 2-SMD, J-Lead
Shielded: Yes
Size: 0.177 inches L x 0.126 inches W (4.50mm x 3.20mm)
Operating Temperature: -55°C to 125°C
MSL: 1 (Unlimited)
REACH Status: Unaffected
HTSUS Code: 8504.50.8000
