The EL3H7(C)TA is a high-isolation voltage, single-channel solid-state relay (SSR) manufactured by Everlight Electronics Co., Ltd. It's designed to provide electrical isolation between a low-voltage control circuit and a high-voltage load circuit, making it suitable for a variety of applications requiring safe and reliable switching.

Applications:

• Industrial Control Systems: Used for switching motors, solenoids, and other industrial loads.
• Home Appliances: Employed in appliances such as washing machines, refrigerators, and air conditioners for controlling various functions.
• Lighting Control: Used for switching lights on and off in lighting systems.
• Telecommunications Equipment: Integrated into telecommunications devices for switching signals and loads.
• Medical Equipment: Used in medical devices for switching circuits and loads safely.

Features:

• High Isolation Voltage: Provides a high level of electrical isolation between the input and output circuits.
• Zero-Crossing Detection: Switches the load at the zero-crossing point of the AC waveform to minimize noise and EMI.
• Low On-Resistance: Minimizes voltage drop and power dissipation across the relay.
• High Load Current: Capable of switching relatively high load currents.
• Compact Package: Small package size allows for easy integration into various devices.
• Optically Isolated: Uses optical isolation to provide electrical isolation and prevent ground loops.

Benefits:

• Enhanced Safety: Provides electrical isolation for safe operation.
• Reduced Noise: Zero-crossing detection minimizes noise and EMI.
• Increased Efficiency: Low on-resistance minimizes power dissipation.
• Reliable Switching: Solid-state design provides reliable and long-lasting switching performance.
• Easy to Use: Simple control interface for easy integration.
• Long Lifespan: Solid-state relays have a longer lifespan compared to electromechanical relays.

Additional Details:

The EL3H7(C)TA typically uses an LED and a phototriac as the input and output components, respectively. The isolation voltage is typically several thousand volts. The operating temperature range is usually between -40°C and +85°C. The trigger current, i.e., the current required to activate the LED and switch the relay, is typically a few milliamperes. The output voltage and current ratings vary depending on the specific version of the relay. The zero-crossing detection feature helps to reduce transient voltages and current surges, which can damage the load or the relay. The solid-state design eliminates the need for moving parts, making the relay more reliable and durable.
