9277010002

Part No 9277010002
Manufacturer FAIR-RITE PRODUCTS
Catalog Ferrite Cores
Description FERRITE CORE U 77
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Core Type U
Material 77
Gap Ungapped
Initial Permeability (µi) 2000
Core Factor (ΣI/A) mm⁻¹ 118.0
Effective Length (le) mm 116.0
Effective Area (Ae) mm2 98.0
Effective Magnetic Volume (Ve) mm3 11300.0
Finish Uncoated
Height 0.812" (20.63mm)
Length 1.620" (41.15mm)
Width 0.460\
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1528140-9277010002
Ultra Librarian 3D Model Ultra Librarian 9277010002 CAD Model
