FDD5353 Real Image FDD5353 real image4050
Same model may have multiple batches, images only for reference.
FDD5353 Real Image FDD5353 real image4050
FDD5353 Real Image FDD5353 real image4050
Same model may have multiple batches, images only for reference.

FDD5353

Part No FDD5353
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 11.5A DPAK
Datasheet
FDD5353 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 11.5A (Ta), 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 65nC @ 10V
Max Input Capacitance 3215pF @ 30V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.1W (Ta), 69W (Tc)
Maximum Rds On at Id,Vgs 12.3 mOhm @ 10.7A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package D-PAK (TO-252AA)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 015941-FDD5353
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FDD5353 CAD Model

Description

FDD5353 Overview

The FDD5353 is a high-current N-channel MOSFET ideal for demanding applications requiring robust performance. This component provides high-efficiency power management with minimal thermal output.

Features and Benefits

  • High current handling capability
  • Superior thermal management
  • Highly reliable in extreme conditions

Applications

  • Inverter circuits
  • Performance audio systems
  • Renewable energy systems
  • Industrial motor drives

Additional Details: Leveraging cutting-edge PowerTrench? technology, the FDD5353 ensures optimal performance under high load conditions.
