FODM8801AR2 Real Image FODM8801AR2 real image17997
Same model may have multiple batches, images only for reference.
FODM8801AR2 Real Image FODM8801AR2 real image17997
FODM8801AR2 Real Image FODM8801AR2 real image17997
Same model may have multiple batches, images only for reference.

FODM8801AR2

Part No FODM8801AR2
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Transistor, Photovoltaic Output
Description FODM8801A, FODM8801B, FODM8801C OptoHiT™ Series, High-Temperature Phototransistor Optocoupler in Half-Pitch Mini-Flat 4-Pin Package
Datasheet
FODM8801AR2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Series OptoHit
Packaging Reel - TR
Number of Channels 1
Voltage - Isolation 3750Vrms
Current Transfer Ratio (Minimum) 80% @ 1mA
Current Transfer Ratio (Maximum) 160% @ 1mA
Turn On / Turn Off Time (Typ) 6μs, 6μs
Rise / Fall Time (Typ) 5μs, 5.5μs
Input Type DC
Output Type Transistor
Output Voltage MAX 75V
Output Current per Channel 30mA
Voltage - Forward (Vf) (Typ) 1.35V
Current - DC Forward (If) (Maximum) 20mA
Vce Saturation (Maximum) 400mV
Operating Temperature Range -40°C ~ 125°C
Mounting SMD
Package 4-SOIC (0.173", 4.40mm)
Manufacturer Package 4-Mini-Flat
Win Source Part Number 1175051-FODM8801AR2
Manufacturer Homepage www.fairchildsemi.com
Family Name FODM8801A
Introduction Date March 18, 2011
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2026
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FODM8801AR2 CAD Model

Description

The FODM8801AR2 is a single channel optocoupler with Transistor output.

  • Voltage Rating: 75V
  • Isolation Voltage: 3750Vrms
  • Input Type: DC
  • Output Type: Transistor
  • Package: 4-SOIC (0.173", 4.40mm)
  • Operating Temperature Range: -40°C to 125°C
  • Current Transfer Ratio: 80% @ 1mA
  • Maximum Current Transfer Ratio: 160% @ 1mA
  • Halogen-Free: Compliant
  • Manufactured in: Thailand
  • Ideal for use in: Isolators
