LM7909CT

Part No LM7909CT
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO -9V 1A TO220-3
Datasheet
LM7909CT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage -35V
Nominal Output Voltage (Min/Fixed) -9V
Dropout Voltage-Max 2V @ 1A (Typ)
Output Current 1A
Operating Supply Current 6mA
PSRR 60dB (120Hz)
Control Protection Features Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Negative Fixed
Output Voltage -9V
Voltage - Dropout (Typical) 2V @ 1A
Mounting Through Hole
Case / Package TO-220-3
Win Source Part Number 092810-LM7909CT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian LM7909CT CAD Model

Description

The LM7909CT is a negative fixed regulator manufactured by Fairchild/ON Semiconductor. It has a TO-220-3 package and operates with a maximum input voltage of -35V.

  • Specifications: Nominal output voltage of -9V, maximum dropout voltage of 2V @ 1A (Typ), operating supply current of 6mA
  • Applications: Suitable for use in applications that require a negative fixed regulator
