MMBT4401

Name: MMBT4401
Brand: Fairchild/ON Semiconductor
SKU: 235361
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MMBT4401
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors (BJT) - Single
Description	TRANS NPN 40V 0.6A SOT23
Datasheet	MMBT4401 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	ON Semiconductor
Packaging	Reel - TR
Status	Active
Transistor Polarity	NPN
Maximum Current Collector	600mA
VCEO Maximum Collector-Emitter Breakdown Voltage	40V
Max Vce (sat)	750mV @ 50mA, 500mA
Typical Gain (hFE) (Min)	100 @ 150mA, 1V
Maximum Power Dissipation	300mW
Frequency - Transition	250MHz
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3 (TO-236)
Win Source Part Number	023762-MMBT4401
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Power Management, Industrial
Package	Tape & Reel (TR);Cut Tape (CT)
Product Status	Active
Transistor Type	NPN
Current - Collector (Ic) (Max)	600mA
Voltage - Collector Emitter Breakdown (Max)	40V
Vce Saturation (Max) @ Ib, Ic	750mV @ 50mA, 500mA
Current - Collector Cutoff (Max)	100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	100 @ 150mA, 1V
Power - Max	300mW
Operating Temperature	-55°C ~ 150°C (TJ)
Grade	-
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Supplier Device Package	SOT-23-3 (TO-236)
Ultra Librarian 3D Model	Ultra Librarian MMBT4401 CAD Model

Alternative Products

Description

The ON Semiconductor MMBT4401 is an NPN transistor that has a maximum current collector of 600mA and a VCEO maximum collector-emitter breakdown voltage of 40V.

Maximum Vce (sat): 750mV @ 50mA and 500mA
Typical Gain (hFE) (Min): 100 @ 150mA and 1V
Maximum Power Dissipation: 300mW
Frequency Transition: 250MHz
Temperature Range: -55°C to 150°C (TJ)
Case/Package: SOT-23-3 (TO-236)
Popularity: High
Supply and Demand: Sufficient
