MMBTA13 Real Image MMBTA13 real image3453
Same model may have multiple batches, images only for reference.
MMBTA13 Real Image MMBTA13 real image3453
MMBTA13 Real Image MMBTA13 real image3453
Same model may have multiple batches, images only for reference.

MMBTA13

Part No MMBTA13
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS NPN DARL 30V 0.3A SOT23
Datasheet
MMBTA13 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Transistor Polarity NPN - Darlington
Maximum Current Collector 300mA
VCEO Maximum Collector-Emitter Breakdown Voltage 30V
Max Vce (sat) 1.5V @ 100μA, 100mA
Collector Cut-off Current(Max) 100nA (ICBO)
Typical Gain (hFE) (Min) 10000 @ 100mA, 5V
Maximum Power Dissipation 225mW
Frequency - Transition 125MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3 (TO-236)
Win Source Part Number 059164-MMBTA13
Ultra Librarian 3D Model Ultra Librarian MMBTA13 CAD Model

Description

The ON Semiconductor 059164-MMBTA13 electronic component is a discrete semiconductor product with an SOT-23-3 (TO-236) case/package.

  • Case/Package: SOT-23-3 (TO-236)
  • Maximum Collector Current: 300mA
  • Maximum Collector-Emitter Breakdown Voltage: 30V
  • Typical Gain (hFE): 10000 @ 100mA, 5V
  • Maximum Power Dissipation: 225mW
  • Manufacturer: ON Semiconductor
  • Status: active
  • Operating Temperature Range: -55°C to 150°C (TJ)
