NC7S86M5X Real Image NC7S86M5X real image3861 NC7S86M5X Real Image1 NC7S86M5X Real Image2 NC7S86M5X Real Image3 NC7S86M5X Real Image4 NC7S86M5X Real Image5
Same model may have multiple batches, images only for reference.
NC7S86M5X Real Image NC7S86M5X real image3861 NC7S86M5X Real Image1 NC7S86M5X Real Image2 NC7S86M5X Real Image3 NC7S86M5X Real Image4 NC7S86M5X Real Image5
NC7S86M5X Real Image NC7S86M5X real image3861 NC7S86M5X Real Image1 NC7S86M5X Real Image2 NC7S86M5X Real Image3 NC7S86M5X Real Image4 NC7S86M5X Real Image5
Same model may have multiple batches, images only for reference.

NC7S86M5X

Part No NC7S86M5X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC GATE XOR 1CH 2-INP SOT-23-5
Datasheet
NC7S86M5X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type XOR (Exclusive OR)
Number of Circuits 1
Number of Inputs 2
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 2.6mA, 2.6mA
Logic Level - Low 0.5V
Logic Level - High 1.5V
Max Propagation Delay @ V, Max CL 17ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Dimension SC-74A, SOT-753
Win Source Part Number 024739-NC7S86M5X
Popularity Medium
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7S86M5X CAD Model

Description

The Fairchild/ON Semiconductor XOR gate with a part number of 024739-NC7S86M5X is a high-speed, low-power, and single-supply IC.

  • Inputs: Two
  • Outputs: One
  • Supply Voltage Range: 2V to 6V
  • Maximum Propagation Delay: 17ns @ 6V, 50pF
  • Quiescent Current: 1μA
  • Package: SOT-23-5
  • Mounting: Surface
