NC7SZ38P5X Real Image NC7SZ38P5X Real Image
Same model may have multiple batches, images only for reference.
NC7SZ38P5X Real Image NC7SZ38P5X Real Image
NC7SZ38P5X Real Image NC7SZ38P5X Real Image
Same model may have multiple batches, images only for reference.

NC7SZ38P5X

Part No NC7SZ38P5X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC GATE NAND 1CH 2-INP SC-70-5
Datasheet
NC7SZ38P5X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 1
Number of Inputs 2
Features Open Drain
Supply Voltage - Operating 1.65 V to 5.5 V
Current - Quiescent (Max) 2μA
Current - Output High, Low -, 32mA
Max Propagation Delay @ V, Max CL 4.3ns @ 5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SC-70-5
Dimension 5-TSSOP, SC-70-5, SOT-353
Win Source Part Number 024841-NC7SZ38P5X
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7SZ38P5X CAD Model

Description

The NC7SZ38P5X is a NAND gate from Fairchild/ON Semiconductor.

  • Feature: Open drain
  • Maximum Propagation Delay: 4.3ns @ 5V and 50pF
  • Quiescent Current: 2μA
  • Supply Voltage Range: 1.65V to 5.5V
  • Maximum Current Output: 32mA
  • Package: SC-70-5
  • Packaging: Reel - TR
  • Quantity: 3k pcs per package
