RB520S

Part No RB520S
Manufacturer Formosa MS
Description 200mA Surface Mount Small Signal Schottky Diodes-30V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Formosa MS
Win Source Part Number 1241917-RB520S
Manufacturer Homepage www.formosams.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RB520S CAD Model

Description

The RB520S is a Schottky barrier diode manufactured by Formosa MS. Schottky diodes are known for their fast switching speeds and low forward voltage drop, which make them ideal for various applications in power management and signal processing. The RB520S offers efficient rectification and protection capabilities.

Applications

  • Voltage clamping
  • Reverse polarity protection
  • Switching mode power supplies (SMPS)
  • DC-DC converters
  • High-frequency rectification

Features

  • Low forward voltage drop: Reduces power loss and increases efficiency.
  • Fast switching speed: Enables high-frequency operation.
  • Small surface mount package: Suitable for compact designs.
  • High surge current capability: Provides protection against transient surges.
  • Pb-Free and RoHS compliant: Environmentally friendly.

Benefits

  • Improved Efficiency: The low forward voltage drop minimizes power dissipation, leading to more efficient circuits and reduced heat generation.
  • Fast Switching: The fast switching speed allows for use in high-frequency applications, providing excellent performance in switching mode power supplies and converters.
  • Compact Design: The small package size enables space-saving designs in portable devices and other applications with limited board space.
  • Reliable Performance: The high surge current capability ensures reliable operation even under transient voltage conditions, protecting sensitive components.
  • Environmentally Friendly: RoHS compliance ensures the diode meets environmental regulations, reducing the environmental impact.

Additional Details

The RB520S typically features a forward voltage drop of around 0.35V at a forward current of 100mA. The maximum repetitive peak reverse voltage is typically around 30V. It is commonly available in surface-mount packages such as SOD-323 or similar. For precise specifications, designers should always refer to the official datasheet from Formosa MS, as these parameters can vary slightly based on the production batch and specific part markings. The diode is well-suited for applications requiring efficient and fast rectification or voltage clamping.
