GBU10K GeneSiC Semiconductor
Same model may have multiple batches, images only for reference.

GBU10K

Part No GBU10K
Manufacturer GeneSiC Semiconductor
Catalog Bridge Rectifiers
Description GLASS PASSIVATED SINGLE-PHASE BRIDGE RECTIFIER(VOLTAGE - 50 to 800 Volts CURRENT - 10.0 Amperes) | BRIDGE RECT 1PHASE 800V 10A GBU
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer GeneSiC Semiconductor
Packaging Bulk
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Maximum) 800V
Current - Average Rectified (Io) 10A
Voltage - Forward (Vf) (Maximum) at If 1.1V at 10A
Current - Reverse Leakage at Vr 5μA at 800V
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package 4-SIP, GBU
Supplier Device Package GBU
Manufacturer Pack Quantity 500
MSL Level 1 (Unlimited)
Win Source Part Number 1177013-GBU10K
Manufacturer Homepage www.panjit.com.tw
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian GBU10K CAD Model

Description

The GBU10K is a single phase standard diode with a through-hole mounting style.

  • Diode Type: Standard
  • Phase: Single
  • Mounting Style: Through-Hole
  • Average Rectified Current: 10A
  • Peak Reverse Voltage (Max): 800V
  • Package: 4-SIP, GBU
  • Temperature Range: -55°C ~ 150°C
  • Manufacturer Pack Quantity: 500
  • MSL Level: 1 (Unlimited)
  • Voltage-Forward (Vf): 1.1V @ 10A
  • Current-Reverse Leakage @ Vr: 5μA @ 800V
  • Manufacturer: GeneSiC Semiconductor
