The RWH-SH-112D is a miniature power relay manufactured by Goodsky. It's designed for a variety of applications requiring reliable switching of moderate to high power loads. This relay is known for its compact size, high contact capacity, and long life, making it suitable for use in industrial control systems, home appliances, and other electronic devices.

Applications

• Home appliances: Switching power to motors, heating elements, and other components in appliances like refrigerators, washing machines, and ovens.
• Industrial control systems: Controlling motors, solenoids, and other actuators in industrial automation equipment.
• HVAC systems: Switching fans, compressors, and other components in heating, ventilation, and air conditioning systems.
• Power supplies: Switching power in power supplies and battery chargers.
• Lighting control: Controlling lighting circuits in commercial and residential buildings.

Features

• Miniature size: Compact design allows for use in space-constrained applications.
• High contact capacity: Capable of switching moderate to high power loads.
• Long life: Designed for reliable operation over an extended period.
• 12VDC coil voltage: Operates on a standard 12VDC coil voltage.
• SPDT contact configuration: Single Pole Double Throw contact configuration provides flexible switching options.

Benefits

• Reliable switching: Ensures consistent and reliable switching of power loads.
• Easy integration: Standard pinout and compact size simplify integration into electronic circuits.
• Long service life: Reduces maintenance costs and downtime.
• Versatile applications: Suitable for a wide range of applications requiring power switching.
• Cost-effective solution: Provides a balance of performance and cost.

Technical Specifications

The RWH-SH-112D relay features a coil voltage of 12VDC. It typically has a contact rating of several amps at 250VAC. The coil resistance and other specific values can be found in the Goodsky datasheet for this part.
