HGTD7N60C3S Harris Corporation
Same model may have multiple batches, images only for reference.

HGTD7N60C3S

Part No HGTD7N60C3S
Manufacturer Harris Corporation
Catalog IGBTs - Single
Description 600 V, 14 A, N-CHANNEL IGBT
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - IGBTs - Single IGBTs
Mfr Harris Corporation
Package Bulk
Product Status Active
Voltage - Collector Emitter Breakdown (Max) 600 V
Current - Collector (Ic) (Max) 14 A
Current - Collector Pulsed (Icm) 56 A
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 7A
Power - Max 60 W
Input Type Standard
Gate Charge 23 nC
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package TO-252AA
Standard Package 33 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 597662-HGTD7N60C3S
Ultra Librarian 3D Model Ultra Librarian HGTD7N60C3S CAD Model

Description

The HGTD7N60C3S is a single IGBT (Insulated Gate Bipolar Transistor) used in discrete semiconductor products and is part of the HGTD7N60C3S series from Harris Corporation.

  • Maximum Power: 60W
  • Collector-Emitter Breakdown Voltage: 600V
  • Maximum Collector Current: 14A
  • Maximum Collector Pulsed Current: 56A
  • Vce(on) @ Vge=15V and Ic=7A: 2V
  • Mounting Type: Surface mountable
  • Package: TO-252-3
  • Operating Temperature Range: -40°C to 150°C
  • Product Status: Active
