DF12(3.0)-10DS-0.5V(86) Real Image
Same model may have multiple batches, images only for reference.

DF12(3.0)-10DS-0.5V(86)

Part No DF12(3.0)-10DS-0.5V(86)
Manufacturer Hirose Electric Co Ltd
Catalog Circular Connectors - Housings
Description CONN RCPT 10POS SMD GOLD / 10 Position Connector Receptacle, Center Strip Contacts Surface Mount Gold
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr Hirose Electric Co Ltd
Series DF12
Package Tape & Reel
Product Status Obsolete
Connector Type Receptacle, Center Strip Contacts
Number of Positions 10
Pitch 0.020" (0.50mm)
Number of Rows 2
Mounting SMD (SMT)
Features Board Guide, Solder Retention
Contact Finish Gold
Contact Finish Thickness 8.00µin (0.203µm)
Mated Stacking Heights 3mm
Height Above Board 0.087" (2.20mm)
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names *DF12(3.0)-10DS-0.5V(86),H11700CT,DF123010DS05V86,H11700DKR,Q9543898,537-0601-8-86,537-0601-8 86,H11700TR
Standard Package 1,000
Win Source Part Number 1167786-DF12(3.0)-10DS-0.5V(86)
Ultra Librarian 3D Model Ultra Librarian DF12(3.0)-10DS-0.5V(86) CAD Model

Description

The DF12 series connector from Hirose Electric Co Ltd is a 10-position receptacle connector with a pitch of 0.020" (0.50mm).

  • Series: DF12
  • Positions: 10
  • Pitch: 0.020" (0.50mm)
  • Contact Finish Thickness: 8.00µin (0.203µm)
  • Mated Stacking Height: 3mm
  • Mounting: SMD (SMT)
  • Height Above Board: 0.087" (2.20mm)
  • Standard Package: 1,000
  • Contact Finish: Gold
  • Style: Board to Board or Cable
