Products specifications Report Issue?

Reference Date Code 09+/08+
Reference case QFP
Manufacturer IC Plus
Win Source Part Number 723986-IP175E
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IP175E CAD Model

Description

The IP175E is a 5-port 10/100 Mbps Fast Ethernet Switch IC manufactured by IC Plus. It is designed to provide a cost-effective and reliable solution for building small Ethernet networks.

Applications

  • Desktop Switches: Used in small desktop Ethernet switches for home and office use.
  • Embedded Networking: Integrated into embedded systems requiring Ethernet connectivity.
  • Industrial Networking: Employed in industrial networking applications for connecting devices in harsh environments.
  • Network Appliances: Used in network appliances such as routers and firewalls.
  • IP Cameras: Integrated into IP cameras for network connectivity.

Features

  • 5-Port Switch: Provides five 10/100 Mbps Fast Ethernet ports.
  • Auto-Negotiation: Supports auto-negotiation for automatic speed and duplex detection.
  • Auto MDI/MDI-X: Supports auto MDI/MDI-X for automatic cable detection.
  • Store-and-Forward Architecture: Uses store-and-forward switching for reliable data transmission.
  • Non-Blocking Architecture: Provides non-blocking architecture for high throughput.
  • Integrated MAC Addresses: Supports integrated MAC address lookup table.
  • LED Indicators: Supports LED indicators for link and activity status.

Benefits

  • Cost-Effective: Provides a cost-effective solution for building small Ethernet networks.
  • Reliable Performance: Store-and-forward architecture ensures reliable data transmission.
  • Easy Integration: Simple design and standard interface facilitate easy integration.
  • High Throughput: Non-blocking architecture ensures high throughput for demanding applications.
  • Flexible Configuration: Supports various configuration options for different networking scenarios.

Additional Details

The IP175E Fast Ethernet Switch IC is designed to provide a reliable and efficient solution for small Ethernet networks. Its store-and-forward architecture ensures that data is transmitted accurately and reliably. The auto-negotiation and auto MDI/MDI-X features simplify installation and configuration. The non-blocking architecture provides high throughput, making it suitable for demanding applications. The integrated MAC address lookup table enables efficient packet forwarding. The IP175E's simple design and standard interface make it easy to integrate into a variety of systems. Its cost-effectiveness and reliable performance make it an excellent choice for building small Ethernet networks.
