Products specifications Report Issue?

Reference Date Code 1648+
Reference case QFN
Manufacturer IC Plus
Win Source Part Number 731395-IP175GHR
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IP175GHR CAD Model

Description

The IP175GHR is a highly integrated 5-port Fast Ethernet switch controller designed by IC Plus. It's a cost-effective solution for integrating networking capabilities into various devices and systems. This chip allows devices to communicate with each other over a local network using Ethernet standards.

Applications

  • SOHO (Small Office/Home Office) Routers: Commonly used in routers to provide multiple Ethernet ports for connecting computers, printers, and other network devices.
  • Network Interface Cards (NICs): Can be integrated into NICs to enable Ethernet connectivity for embedded systems.
  • Industrial Ethernet Switches: Suitable for building industrial-grade Ethernet switches for automation and control systems.
  • Embedded Systems: Used in devices that require Ethernet connectivity, such as IP cameras, network storage devices, and IoT gateways.

Features

  • 5-Port 10/100Mbps Fast Ethernet Switch: Supports both 10Mbps and 100Mbps Ethernet speeds on all five ports.
  • Integrated MAC and PHY: Includes Media Access Controller (MAC) and Physical Layer (PHY) functionality for Ethernet communication.
  • Auto-Negotiation: Automatically detects and configures the speed and duplex mode of connected devices.
  • Auto MDI/MDIX: Eliminates the need for crossover cables by automatically detecting and configuring the cable type.
  • Store-and-Forward Architecture: Ensures data integrity by storing packets before forwarding them to their destination.
  • Supports VLAN Tagging: Enables the creation of virtual LANs (VLANs) for network segmentation and security.
  • Quality of Service (QoS): Prioritizes network traffic to ensure smooth performance for critical applications.
  • Broadcast Storm Protection: Prevents network congestion caused by excessive broadcast traffic.

Benefits

  • Cost-Effective: Provides a low-cost solution for adding Ethernet switching capabilities to devices.
  • Easy Integration: The integrated MAC and PHY simplify system design and reduce the number of external components.
  • High Performance: Supports Fast Ethernet speeds for fast and reliable network communication.
  • Flexible Configuration: Supports various configuration options, including VLAN tagging and QoS.
  • Robust Performance: The store-and-forward architecture and broadcast storm protection ensure reliable network operation.

Technical Specifications

The IP175GHR operates at a voltage of typically 3.3V. It supports IEEE 802.3 and IEEE 802.3u Ethernet standards. The switch controller features a non-blocking architecture, ensuring that all ports can operate at full speed simultaneously. It includes an integrated address lookup table for efficient packet forwarding. The device is typically available in a QFP (Quad Flat Package) for easy surface mounting. It also supports loopback detection to prevent network loops. Furthermore, the switch contains diagnostic LEDs, providing link and activity status information for each port.
