1ED020I12FA2XUMA2 Infineon Technologies 1ED020I12FA2XUMA2 Real Image
Same model may have multiple batches, images only for reference.
1ED020I12FA2XUMA2 Infineon Technologies 1ED020I12FA2XUMA2 Real Image
1ED020I12FA2XUMA2 Infineon Technologies 1ED020I12FA2XUMA2 Real Image
Same model may have multiple batches, images only for reference.

1ED020I12FA2XUMA2

Part No 1ED020I12FA2XUMA2
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description IC IGBT DVR 1200V 2A DSO20
Datasheet
1ED020I12FA2XUMA2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Infineon Technologies
Series EiceDriver
Packaging Reel package
Driven Configuration High-Side or Low-Side
Channel Type Single
Number of Drivers 1
Gate Type IGBT
Operating Supply Voltage 13 V ~ 20 V
Logic Voltage - VIL, VIH 1.5V, 3.5V
Current - Peak Output (Source, Sink) 2A, 2A
Input Type Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap) 1200V
Rise / Fall Time (Typ) 30ns, 50ns
Operating Temperature Range -40°C ~ 150°C (TJ)
Mounting SMD
Package 20-SOIC (0.295", 7.50mm Width)
Manufacturer Package PG-DSO 20
Win Source Part Number 760763-1ED020I12FA2XUMA2
Popularity Medium
Supply and Demand Status Limited
Family Name 1ED020I12FA2
ECCN EAR99
Country of Origin Indonesia
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian 1ED020I12FA2XUMA2 CAD Model

Description

The Infineon Technologies 760763-1ED020I12FA2XUMA2 is a single channel IGBT gate driver of EiceDriver series.

  • Series: EiceDriver
  • Popularity: Medium
  • Supply and Demand Status: Limited
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Operating Supply Voltage: 13 V ~ 20 V
  • Configuration: High-Side or Low-Side
  • Peak Output: 2A, 2A
