Same model may have multiple batches, images only for reference.

BSC026N08NS5ATMA1

Name: BSC026N08NS5ATMA1
Brand: Infineon Technologies
SKU: 439058
Availability: InStock
Rating: 4.91 (48 reviews)

Get a Quote

Part No	BSC026N08NS5ATMA1
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 80V 23A 8TDSON
Datasheet	BSC026N08NS5ATMA1 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	80V
Continuous Drain Current at 25°C	23A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Gate-Source Threshold Voltage	3.8V @ 115μA
Max Gate Charge	92nC @ 10V
Max Input Capacitance	6800pF @ 40V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.5W (Ta), 156W (Tc)
Maximum Rds On at Id,Vgs	2.6 mOhm @ 50A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	PG-TDSON-8
Dimension	8-PowerTDFN
Win Source Part Number	1024324-BSC026N08NS5ATMA1
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian BSC026N08NS5ATMA1 CAD Model

Alternative Products

Description

The Infineon Technologies BSC026N08NS5ATMA1 is an N-channel MOSFET transistor with a drain-source breakdown voltage of 80V and a continuous drain current of 23A (Ta) and 100A (Tc) @ 25°C.

Maximum Power Dissipation: 2.5W (Ta) and 156W (Tc)
Package: PG-TDSON-8
Mounting Technology: Surface-mount
Drive Voltage (Rds On): 6V (min), 10V (max)
Gate-Source Threshold Voltage: 3.8V @ 115μA
Maximum Gate Charge: 92nC @ 10V
Maximum Input Capacitance: 6800pF @ 40V
