Same model may have multiple batches, images only for reference.
ICE3B3565P Infineon Technologies
Same model may have multiple batches, images only for reference.

ICE3B3565P

Part No ICE3B3565P
Manufacturer Infineon Technologies
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE CTRLR SMPS OTP TO220
Datasheet
ICE3B3565P Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Obsolete(EOL)
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 650V
Topology Flyback
Voltage - Start Up 15V
Supply Voltage - Operating 8.5 V to 21 V
Duty Cycle 72%
Frequency - Switching 67kHz
Power (Watts) 170W
Fault Protection Current Limiting, Open Loop, Over Load, Over Temperature, Over Voltage
Control Features Soft Start
Temperature Range - Operating -25°C to 130°C (TJ)
Case / Package PG-TO220-6
Mounting Through Hole
Win Source Part Number 068364-ICE3B3565P
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ICE3B3565P CAD Model

Description

The Infineon Technologies ICE3B3565P is an integrated circuit with a flyback topology and an internal switch.

  • Package: PG-TO220-6
  • Isolation: Isolated
  • Voltage Breakdown: 650V
  • Duty Cycle: 72%
  • Switching Frequency: 67kHz
  • Fault Protection: Current Limiting, Open Loop, Over Load, Over Temperature, Over Voltage
  • Power Rating: 170W
  • Supply Voltage Range: 8.5V to 21V
  • Status: Obsolete (EOL)
