IPW60R045CP Infineon Technologies IPW60R045CP Real Image
Same model may have multiple batches, images only for reference.
IPW60R045CP Infineon Technologies IPW60R045CP Real Image
IPW60R045CP Infineon Technologies IPW60R045CP Real Image
Same model may have multiple batches, images only for reference.

IPW60R045CP

Part No IPW60R045CP
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 650V 60A TO-247 / Trans MOSFET N-CH 650V 60A 3-Pin(3+Tab) TO-247 Tube
Datasheet
IPW60R045CP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 650V
Continuous Drain Current at 25°C 60A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 3.5V @ 3mA
Max Gate Charge 190nC @ 10V
Max Input Capacitance 6800pF @ 100V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 431W (Tc)
Maximum Rds On at Id,Vgs 45 mOhm @ 44A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package PG-TO247-3
Dimension TO-247-3
Win Source Part Number 017330-IPW60R045CP
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name IPW60R045CP
Introduction Date June 19, 2006
ECCN EAR99
Country of Origin Austria, China, Germany, Malaysia, Philippines
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian IPW60R045CP CAD Model

Description

The Infineon Technologies 017330-IPW60R045CP MOSFET is a high-power N-channel device that can handle up to 650V with a continuous drain current of 60A @ 25°C.

  • On-Resistance: 45mΩ @ 44A and 10V gate-source voltage
  • Package: PG-TO247-3
  • Maximum Power Dissipation: 431W @ Tc
  • Maximum Gate-Source Voltage: ±20V
  • Gate-Source Threshold Voltage: 3.5V @ 3mA
  • Applications: Power supplies, motor control, and lighting systems
  • Packaging: Tube/rail
  • Part Status: Common-used with high popularity
